Mains Filters DE2B3SA471KA3BY02F 400Vac 470pF X1 Y2 Safety Disc AC Ceramic Capacitor

1000 Pieces
MOQ
Mains Filters DE2B3SA471KA3BY02F 400Vac 470pF X1 Y2 Safety Disc AC Ceramic Capacitor
Eigenschaften Galerie Produkt-Beschreibung Fordern Sie ein Zitat
Eigenschaften
Technische Daten
Type: CERAMIC CAPACITOR
D/C: HS210319031
Capacitance: 470pF
Tolerance: ±10%
Package Type: Through Hole
Rated Voltage: Other
Operating Temperature: -30°C ~ 85°C
Brand: AC Capacitor
Specification: Not Applicable
Voltage - Rated: 400VAC
Applications: AC line filters
Temperature Coefficient: B
Voltage - Breakdown: AC2600V
Capacitance Range: ±10%
SKYPE: lexce-xu
Email: sales(at)hua-sing.com
Whatsapp/Wechat: +86 132 7061 6396
Grundinformation
Zahlung und Versand AGB
Produkt-Beschreibung

Safety Standard Certified Lead Type Disc Ceramic Capacitors for General Purpose
Features
1. Impulse voltage guaranteed 8kV0-p.
2. Operating temperature range guaranteed up to 125°C.
3. Dielectric strength: AC2600V
4. Class X1/Y2 capacitors certified by ENEC(VDE)/UL/CQC.
5. Coated with flame-retardant halogen-free* epoxy resin (conforming to UL94V-0 standard).
* Cl=900ppm max., Br=900ppm max. and Cl+Br=1500ppm max.
6. Taping available for automatic insertion.
7. Rated Voltage: X1: AC440V(r.m.s.), Y2: AC400V(r.m.s.)

Applications
Ideal for use as X/Y capacitors for AC line filters
and primary-secondary coupling on switching power supplies and AC adapters.

Do not use these products in any automotive power train or safety equipment including battery chargers for electric vehicles and plug-in hybrids.Only Murata products clearly stipulated as "for Automotive use" on its catalog can be used
for automobile applications such as power train and safety equipment.

AC Rated Voltage Temp. Char. Capacitance Body Dia. D Lead Spacing F
(mm)		 Body Thickness T Long Leads Short Leads Taping
400Vac(r.m.s.) SL 10pF±10% 7.0mm max. 7.5 5.0mm max. DE21XSA100KA3BY02F DE21XSA100KJ3BY02F DE21XSA100KN3AY02F
400Vac(r.m.s.) SL 15pF±10% 6.0mm max. 7.5 6.0mm max. DE21XSA150KA3BY02F DE21XSA150KJ3BY02F DE21XSA150KN3AY02F
400Vac(r.m.s.) SL 22pF±10% 6.0mm max. 7.5 5.0mm max. DE21XSA220KA3BY02F DE21XSA220KJ3BY02F DE21XSA220KN3AY02F
400Vac(r.m.s.) SL 33pF±10% 7.0mm max. 7.5 5.0mm max. DE21XSA330KA3BY02F DE21XSA330KJ3BY02F DE21XSA330KN3AY02F
400Vac(r.m.s.) SL 47pF±10% 7.0mm max. 7.5 5.0mm max. DE21XSA470KA3BY02F DE21XSA470KJ3BY02F DE21XSA470KN3AY02F
400Vac(r.m.s.) SL 68pF±10% 9.0mm max. 7.5 5.0mm max. DE21XSA680KA3BY02F DE21XSA680KJ3BY02F DE21XSA680KN3AY02F
400Vac(r.m.s.) B 100pF±10% 6.0mm max. 7.5 5.0mm max. DE2B3SA101KA3BY02F DE2B3SA101KJ3BY02F DE2B3SA101KN3AY02F
400Vac(r.m.s.) B 150pF±10% 6.0mm max. 7.5 5.0mm max. DE2B3SA151KA3BY02F DE2B3SA151KJ3BY02F DE2B3SA151KN3AY02F
400Vac(r.m.s.) B 220pF±10% 6.0mm max. 7.5 6.0mm max. DE2B3SA221KA3BY02F DE2B3SA221KJ3BY02F DE2B3SA221KN3AY02F
400Vac(r.m.s.) B 330pF±10% 6.0mm max. 7.5 5.0mm max. DE2B3SA331KA3BY02F DE2B3SA331KJ3BY02F DE2B3SA331KN3AY02F
400Vac(r.m.s.) B 470pF±10% 7.0mm max. 7.5 5.0mm max. DE2B3SA471KA3BY02F DE2B3SA471KJ3BY02F DE2B3SA471KN3AY02F
400Vac(r.m.s.) B 680pF±10% 8.0mm max. 7.5 5.0mm max. DE2B3SA681KA3BY02F DE2B3SA681KJ3BY02F DE2B3SA681KN3AY02F
400Vac(r.m.s.) E 1000pF±20% 7.0mm max. 7.5 5.0mm max. DE2E3SA102MA3BY02F DE2E3SA102MJ3BY02F DE2E3SA102MN3AY02F
400Vac(r.m.s.) E 1500pF±20% 8.0mm max. 7.5 5.0mm max. DE2E3SA152MA3BY02F DE2E3SA152MJ3BY02F DE2E3SA152MN3AY02F
400Vac(r.m.s.) E 2200pF±20% 9.0mm max. 7.5 5.0mm max. DE2E3SA222MA3BY02F DE2E3SA222MJ3BY02F DE2E3SA222MN3AY02F
400Vac(r.m.s.) E 3300pF±20% 12.0mm max. 7.5 5.0mm max. DE2E3SA332MA3BY02F DE2E3SA332MJ3BY02F DE2E3SA332MN3AY02F
400Vac(r.m.s.) E 4700pF±20% 13.0mm max. 7.5 5.0mm max. DE2E3SA472MA3BY02F DE2E3SA472MJ3BY02F DE2E3SA472MN3AY02F
400Vac(r.m.s.) E 10000pF±20% 17.0mm max. 7.5 6.0mm max. DE2E3SA103MA3BY02F DE2E3SA103MJ3BY02F DE2E3SA103MN3AY02F
